CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA TT-R230 2021

VALVE

Item numbers

CRANKSHAFT ASSY

3RW114000000 3RW114000000

1 252,80 €

Unit Price Incl. Tax

PIN, CRANK 1

5H0116810000 5H0116810000

85,67 €

Unit Price Incl. Tax

BEARING, CYLINDRICAL (5H0)

93310530J300 93310530J300

68,79 €

Unit Price Incl. Tax

ROD, CONNECTING

29U116510000 29U116510000

112,53 €

Unit Price Incl. Tax

BRG, R-B 6306 72MM 351G KY

933063061100

933063061500

48,56 €

Unit Price Incl. Tax

PISTON (STD)

1KH1163101C0 1KH1163101C0

203,96 €

Unit Price Incl. Tax

PISTON (0.50MM O/S)

1KH116360100 1KH116360100

187,83 €

Unit Price Incl. Tax

PISTON (1.00MM O/S)

1KH116380100 1KH116380100

187,83 €

Unit Price Incl. Tax

PISTON RING SET

29U116100000 29U116100000

38,88 €

Unit Price Incl. Tax

PISTON RING SET

29U116102000 29U116102000

38,88 €

Unit Price Incl. Tax

PISTON RING SET (STD)

29U116104000

4BD116100000

38,88 €

Unit Price Incl. Tax

PIN, PISTON

15A116330000

58L116330000

48,60 €

Unit Price Incl. Tax

CIRCLIP (1L9) 5PK

934501704400 934501704400

2,98 €

Unit Price Incl. Tax

WASHER, PLATE (5H0)

90201201E400 90201201E400

20,69 €

Unit Price Incl. Tax

BOSS, BUFFER

5H0114960000 5H0114960000

124,83 €

Unit Price Incl. Tax

SPRING COMPRESSION341114880000

905012113300 905012113300

5,60 €

Unit Price Incl. Tax

PIN, DOWEL 5PK

936051009000 936051009000

3,67 €

Unit Price Incl. Tax

GEAR, DRIVE

5H0115360000 5H0115360000

90,04 €

Unit Price Incl. Tax

WASHER, CLAW (5H0)

902142002300 902142002300

10,74 €

Unit Price Incl. Tax

PIN, CLEVIS (5H0)

902400708300 902400708300

17,08 €

Unit Price Incl. Tax

SPRING, COMPRESSION (5H0)

905010762900 905010762900

2,90 €

Unit Price Incl. Tax

PIN, DOWEL (5H0)

936021317700 936021317700

3,10 €

Unit Price Incl. Tax

GEAR, BALANCE WT

5H0115310000 5H0115310000

130,97 €

Unit Price Incl. Tax

WEIGHT 1

1KH114540000 1KH114540000

305,74 €

Unit Price Incl. Tax

ROULEMENT

93306205X400 93306205X400

Not available

ROULEMENT

93306304YR00 93306304YR00

Not available

KEY, STRAIGHT(34K)

902820501300

902820506500

3,75 €

Unit Price Incl. Tax

WASHER, LOCK (15Y)

902151420500 902151420500

2,68 €

Unit Price Incl. Tax

NUT (5H0)

901701428400 901701428400

1,93 €

Unit Price Incl. Tax

KEY, WOODRUFF

902800504800

902800501300

11,98 €

Unit Price Incl. Tax

WASHER, PLATE(52H)

902011050800

90201102J500

12,67 €

Unit Price Incl. Tax

BOLT (341)

901011018800 901011018800

5,52 €

Unit Price Incl. Tax

PLATE, BREATHER 2

1KH111450000 1KH111450000

18,51 €

Unit Price Incl. Tax

OIL SEAL (5Y1)

931012510600 931012510600

8,11 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
