CRANKCASE

COVER - ENGINE 1 FOR YAMAHA TT-R230 2006

STARTER CLUTCH

(1) 1C6-E5411-00-WN

COVER, CRANKCASE 1

(2) 4BE-15451-03

GASKET, CRANKCASE COVER 1

(3) 99530-12016

PIN, DOWEL

(4) 90105060A000

BOLT, WASHER BASED(4KG)

(5) 950270603500

BOLT, SMALL FLANGE

(6) 90340-14128

PLUG, STRAIGHT SCREW(3RW)

(7) 932101436900

O-RING (2H9)

(8) 90340-32123

PLUG, STRAIGHT SCREW(3AW)

(9) 932103217200

O-RING (341)

(10) 1C6-E5758-00

GUIDE, ROPE

(11) 920170601000

BOLT, BUTTON HEAD

(12) 1C6-E5484-00

CLAMP 2

(13) 1C6-E7466-00

GUIDE, CHAIN

(14) 1C6-E5420-00-WN

CRANKCASE COVER ASSY 2

(15) 90105060A000

BOLT, WASHER BASED(4KG)

(16) 4VW-WE543-00

COVER, CRANKCASE 3

(17) 4BE-15462-00

GASKET, CRANKCASE COVER 3

(18) 99530-12016

PIN, DOWEL

(19) 90105060A000

BOLT, WASHER BASED(4KG)

(20) 950270603500

BOLT, SMALL FLANGE

(21) 950270604500

BOLT, SMALL FLANGE

(22) 3Y1153631000

PLUG, OIL

(23) 932101912300

O-RING

(24) 3Y11536100

GAUGE LEVEL

(25) 90462-08225

CLAMP(4AJ)

	Part number	Description	Qty
# 1	1C6-E5411-00-WN 1C6E541100WN 1C6E541100WN	COVER, CRANKCASE 1	228,25 €
# 2	4BE-15451-03 4BE1545103 4BE1545103	GASKET, CRANKCASE COVER 1	26,33 €
# 3	99530-12016 9953012016 9953012016	PIN, DOWEL	3,43 €
# 4	9502M-06025 90105060A000 9502M06025	BOLT, WASHER BASED(4KG)	1,78 €
# 5	9502M-06035 950270603500 9502M06035	BOLT, SMALL FLANGE	0,46 €
# 6	90340-14128 9034014128 9034014128	PLUG, STRAIGHT SCREW(3RW)	16,37 €
# 7	93210-14800 932101436900 9321014800	O-RING (2H9)	1,23 €
# 8	90340-32123 9034032123 9034032123	PLUG, STRAIGHT SCREW(3AW)	10,79 €
# 9	93210-32800 932103217200 9321032800	O-RING (341)	5,07 €
# 10	1C6-E5758-00 1C6E575800 1C6E575800	GUIDE, ROPE	10,43 €
# 11	9201M-06010 920170601000 9201M06010	BOLT, BUTTON HEAD	1,61 €
# 12	1C6-E5484-00 1C6E548400 1C6E548400	CLAMP 2	7,26 €
# 13	1C6-E7466-00 1C6E746600 1C6E746600	GUIDE, CHAIN	Not available	0,00 €
# 14	1C6-E5420-00-WN 1C6E542000WN 1C6E542000WN	CRANKCASE COVER ASSY 2	Not available	0,00 €
# 15	9502M-06025 90105060A000 9502M06025	BOLT, WASHER BASED(4KG)	1,78 €
# 16	4VW-WE543-00 4VWWE54300 4VWWE54300	COVER, CRANKCASE 3	811,05 €
# 17	4BE-15462-00 4BE1546200 4BE1546200	GASKET, CRANKCASE COVER 3	26,33 €
# 18	99530-12016 9953012016 9953012016	PIN, DOWEL	3,43 €
# 19	9502M-06025 90105060A000 9502M06025	BOLT, WASHER BASED(4KG)	1,78 €
# 20	9502M-06035 950270603500 9502M06035	BOLT, SMALL FLANGE	0,46 €
# 21	9502M-06045 950270604500 9502M06045	BOLT, SMALL FLANGE	0,50 €
# 22	3Y1-15363-00 3Y1153631000 3Y11536300	PLUG, OIL	13,85 €
# 23	9321019123 9321019123	O-RING	Not available	0,00 €
# 24	3Y11536100 3Y11536100 3Y11536100	GAUGE LEVEL	Not available	0,00 €
# 25	90462-08225 9046208225 9046208225	CLAMP(4AJ)	7,32 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the COVER - ENGINE 1 of your Yamaha TT-R230 of 2006. Let us know if you have any questions.
