CYLINDER HEAD

CRANKSHAFT / PISTON FOR YAMAHA SNOSCOOT 2018

CAMSHAFT & VALVES

Item numbers

PISTON (STD)

7DHE163110A0 7DHE163110A0

78,95 €

Unit Price Incl. Tax

PISTON (0.25MM O/S)

7DHE16350000 7DHE16350000

55,33 €

Unit Price Incl. Tax

PISTON (0.50MM O/S)

7DHE16360000 7DHE16360000

55,33 €

Unit Price Incl. Tax

PISTON RING SET (STD)

7D9E16100000 7D9E16100000

44,33 €

Unit Price Incl. Tax

PISTON RING SET (0.25MM O/S)

7DHE16101000

7D9E16101000

44,33 €

Unit Price Incl. Tax

PISTON RING SET (0.50MM O/S)

7DHE16102000 7DHE16102000

44,33 €

Unit Price Incl. Tax

CIRCLIP

934501782800 934501782800

2,12 €

Unit Price Incl. Tax

PIN, PISTON

7CNE16330000 7CNE16330000

23,21 €

Unit Price Incl. Tax

CONNECTING ROD ASSY

7CNE16501100 7CNE16501100

157,24 €

Unit Price Incl. Tax

BOLT, CONNECTING ROD

7CNE16540000 7CNE16540000

3,79 €

Unit Price Incl. Tax

CRANKSHAFT ASSY

7DHE14003000 7DHE14003000

425,25 €

Unit Price Incl. Tax

KEY, WOODRUFF

902800480100 902800480100

8,36 €

Unit Price Incl. Tax

SHIM, CRANK 1

7CNE15610000 7CNE15610000

2,79 €

Unit Price Incl. Tax

KEY, STRAIGHT (7H0)

902820503500 902820503500

8,14 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
