STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA YFM200DX 1989

TRANSMISSION

(1) 3GC-16611-00

CLUTCH HOUSING COMP.

(2) 21V-16664-00

BEARING,ONE WAY

(3) 21V-16665-01

RETAINER, BEARING

(4) 90201-404M6

WASHER, PLATE(3GC)

(5) 4BD166200000

CLUTCH CARRIER ASSY

(6) 3GC166260100

SPRING, CLUTCH WEIGHT 1

(7) 90201-266F6

WASHER, PLATE (21V)

(8) 90215-22259

WASHER, LOCK(1YW)

(9) 90170-22371

NUT(1NU)

(10) 2HT-16150-00

PRIMARY DRIVEN GEAR COMP.

(11) 5H0-16154-00

PLATE, THRUST 1

(12) 21V163710100

BOSS, CLUTCH

(13) 3XP163210000

PLATE, FRICTION

(14) 257-16324-00

PLATE, CLUTCH

(15) 21V-16351-00

PLATE, PRESSURE 1

(16) 90501243J700

SPRING, COMPRESSION(3GC)

(17) 21V-16352-00

PLATE, PRESSURE 2

(18) 901590501100

SCREW, WITH WASHER (537)

(19) 93306-00004

BRG,R-B 6000 26MM 19G KY

(20) 1YW163580000

PLATE, PUSH

(21) 902151418600

WASHER, LOCK (25G)

(22) 90170-14284

NUT (5H0)

(23) 90338-26136

PLUG (21V)

(24) 93420-28055

CIRCLIP (3Y1)

	Part number	Description	Qty
# 1	3GC-16611-00 3GC1661100 3GC1661100	CLUTCH HOUSING COMP.	467,24 €
# 2	21V-16664-00 21V1666400 21V1666400	BEARING, ONE WAY	81,93 €
# 3	21V-16665-01 21V1666501 21V1666501	RETAINER, BEARING	Not available	0,00 €
# 4	90201-404M6 90201404M6 90201404M6	WASHER, PLATE(3GC)	7,77 €
# 5	3GC-16620-00 4BD166200000 3GC1662000	CLUTCH CARRIER ASSY	640,03 €
# 6	3GC-16626-00 3GC166260100 3GC1662600	SPRING, CLUTCH WEIGHT 1	14,54 €
# 7	90201-266F6 90201266F6 90201266F6	WASHER, PLATE (21V)	4,85 €
# 8	90215-22259 9021522259 9021522259	WASHER, LOCK(1YW)	13,07 €
# 9	90170-22371 9017022371 9017022371	NUT(1NU)	12,84 €
# 10	2HT-16150-00 2HT1615000 2HT1615000	PRIMARY DRIVEN GEAR COMP.	Not available	0,00 €
# 11	5H0-16154-00 5H01615400 5H01615400	PLATE, THRUST 1	22,72 €
# 12	21V-16371-00 21V1637100	BOSS, CLUTCH	Not available	0,00 €
# 13	21V-16321-00 3XP163210000 21V1632100	PLATE, FRICTION	24,33 €
# 14	257-16324-00 2571632400 2571632400	PLATE, CLUTCH	20,61 €
# 15	21V-16351-00 21V1635100 21V1635100	PLATE, PRESSURE 1	Not available	0,00 €
# 16	90501-24785 90501243J700 9050124785	SPRING, COMPRESSION(3GC)	6,68 €
# 17	21V-16352-00 21V1635200 21V1635200	PLATE, PRESSURE 2	Not available	0,00 €
# 18	901590501100 901590501100 901590501100	SCREW, WITH WASHER (537)	4,24 €
# 19	93306-00004 9330600004 9330600004	BRG, R-B 6000 26MM 19G KY	21,00 €
# 20	21V-16358-00 1YW163580000 21V1635800	PLATE, PUSH	7,17 €
# 21	90215-14263 902151418600 9021514263	WASHER, LOCK (25G)	5,85 €
# 22	90170-14284 9017014284 9017014284	NUT (5H0)	1,37 €
# 23	90338-26136 9033826136 9033826136	PLUG (21V)	7,55 €
# 24	93420-28055 9342028055 9342028055	CIRCLIP (3Y1)	1,61 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha YFM200DX of 1989. Let us know if you have any questions.
