INTAKE

CARBURETOR FOR YAMAHA AG 200 F 2012

EXHAUST

Item numbers

CARBURETOR ASSY 1

53C149010000 53C149010000

570,33 €

Unit Price Incl. Tax

PILOT SCREW SET

36X141050000 36X141050000

41,34 €

Unit Price Incl. Tax

JET, MAIN (#125)

3G2142312500 3G2142312500

15,61 €

Unit Price Incl. Tax

SPRING, DIAPHRAGM

36X149330100 36X149330100

25,10 €

Unit Price Incl. Tax

NEEDLE SET (4FP40)

36X1490J0000 36X1490J0000

59,26 €

Unit Price Incl. Tax

NOT AVAILABLE

36X1410A0000

Not available

GASKET, FLOAT CHAMBER

46X149840000 46X149840000

15,71 €

Unit Price Incl. Tax

JET, PILOT (# 35)

4G0141423500

4G01414235A0

15,99 €

Unit Price Incl. Tax

SCREW, PLUG

3F7149910000 3F7149910000

7,24 €

Unit Price Incl. Tax

NOZZLE, MAIN

36X149414200 36X149414200

120,72 €

Unit Price Incl. Tax

WASHER, MAIN JET

137141530000 137141530000

3,32 €

Unit Price Incl. Tax

JET, MAIN #117.5

6201423A7400 6201423A7400

24,80 €

Unit Price Incl. Tax

WASHER, MAIN JET

36X141530000 36X141530000

18,13 €

Unit Price Incl. Tax

FLOAT

4G0149850000 4G0149850000

105,28 €

Unit Price Incl. Tax

SCREW, PAN HEAD(3XP)

985070400600

985170400600

2,98 €

Unit Price Incl. Tax

NOT AVAILABLE

36X141460000

Not available

PIN, FLOAT

537141860000 537141860000

4,56 €

Unit Price Incl. Tax

NEEDLE VALVE SET

25G141072000 25G141072000

73,12 €

Unit Price Incl. Tax

DIAPHRAGM ASSY

36X149400000 36X149400000

55,12 €

Unit Price Incl. Tax

SCREW, PAN HEAD(JN2)

985070500800 985070500800

1,14 €

Unit Price Incl. Tax

NOT AVAILABLE

36X141970000

Not available

PLUG, DRAIN

36X141910000

12R141910000

8,70 €

Unit Price Incl. Tax

STOP SCREW SET

36X1490K0000 36X1490K0000

19,94 €

Unit Price Incl. Tax

SCREW, W/WASHER

976070411400 976070411400

2,00 €

Unit Price Incl. Tax

PIPE

3JN141960000

26H141970100

19,48 €

Unit Price Incl. Tax

CLIP

25G149370000 25G149370000

5,82 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
