SEAT / LOCK FOR YAMAHA FX HO 2020

SEAT / LOCK 2

Item numbers

DOUBLE SEAT ASSY

F3XU371A9100

F3XU371A9000

846,22 €

Unit Price Incl. Tax

COVER, SEAT 1

F3XU371B9000 F3XU371B9000

441,16 €

Unit Price Incl. Tax

PACKING

F3XU26640100 F3XU26640100

134,07 €

Unit Price Incl. Tax

SEAT LOCK ASSY

F2CU38500000 F2CU38500000

26,45 €

Unit Price Incl. Tax

BOLT, WITH WASHER

90119069UP00

901190680800

2,84 €

Unit Price Incl. Tax

SINGLE SEAT ASSY

F3XU372A9000 F3XU372A9000

511,30 €

Unit Price Incl. Tax

COVER, SEAT

F3XU372B9000 F3XU372B9000

356,96 €

Unit Price Incl. Tax

PACKING 5

F3XU266D0100 F3XU266D0100

128,61 €

Unit Price Incl. Tax

SEAT LOCK ASSY

F2CU38500000 F2CU38500000

26,45 €

Unit Price Incl. Tax

BOLT, WITH WASHER

90119069UP00

901190680800

2,84 €

Unit Price Incl. Tax

DECK BEAM ASSY

F2SU890L0500 F2SU890L0500

100,07 €

Unit Price Incl. Tax

GH1U37740000 GH1U37740000

24,50 €

Unit Price Incl. Tax

WASHER, PLATE

90201109U600 90201109U600

4,70 €

Unit Price Incl. Tax

WASHER

9299R1020000 9299R1020000

0,98 €

Unit Price Incl. Tax

NUT, FLANGE

9572R1030000 9572R1030000

7,75 €

Unit Price Incl. Tax

PACKING 1

F2SU375E0000 F2SU375E0000

10,09 €

Unit Price Incl. Tax

PACKING

F2SU82440000 F2SU82440000

1,93 €

Unit Price Incl. Tax

BOLT, WITH WASHER

901190882800 901190882800

4,27 €

Unit Price Incl. Tax

NUT LOCK

F3YU142L0000 F3YU142L0000

2,90 €

Unit Price Incl. Tax

CASE ASSY 1

F2CU591A0300 F2CU591A0300

103,52 €

Unit Price Incl. Tax

CAP, CASE

F2CU591C0000 F2CU591C0000

15,07 €

Unit Price Incl. Tax

PACKING, CASE

F2CU591D0100 F2CU591D0100

7,75 €

Unit Price Incl. Tax

PACKING, 6

F2CU266E0000 F2CU266E0000

20,53 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SEAT / LOCK of your Yamaha FX HO of 2020. Let us know if you have any questions.
