MASTER CYLINDER

STAND / FOOTREST FOR YAMAHA SMAX 2020

LEG SHIELD

Item numbers

BOARD FOOTREST

1DKF74810100 1DKF74810100

41,93 €

Unit Price Incl. Tax

BOLT, WITH WASHER

901190682100 901190682100

0,84 €

Unit Price Incl. Tax

NUT, SPRING

901830581600

901830582700

0,73 €

Unit Price Incl. Tax

SCREW, TAPPING(4TV) 5PK

977075001600

901670507700

1,14 €

Unit Price Incl. Tax

BOLT, HEX. SOCKET B

901110683100 901110683100

1,03 €

Unit Price Incl. Tax

CAP 1

5HKF74750000 5HKF74750000

1,89 €

Unit Price Incl. Tax

STAND, MAIN

1DKXF7110000

1DKXF7110100

176,00 €

Unit Price Incl. Tax

STOPPER, MAIN STAN

5S9F71140100 5S9F71140100

2,48 €

Unit Price Incl. Tax

STOPPER, MAIN STAN

1DKF71140000 1DKF71140000

4,49 €

Unit Price Incl. Tax

SHAFT, MAIN STAND

52SF71120000 52SF71120000

15,49 €

Unit Price Incl. Tax

CIRCLIP(58Y) 5PK

990011260000 990011260000

2,90 €

Unit Price Incl. Tax

SPRING, TENSION

905062880400 905062880400

5,82 €

Unit Price Incl. Tax

SPRING, TENSION

905063680000 905063680000

8,70 €

Unit Price Incl. Tax

HOSE

904452180800 904452180800

2,00 €

Unit Price Incl. Tax

HOOK

52SF72540000 52SF72540000

2,52 €

Unit Price Incl. Tax

STAND, SIDE

2LDF73110000

2LDF73110033

49,67 €

Unit Price Incl. Tax

BOLT

901091000500 901091000500

2,23 €

Unit Price Incl. Tax

NUT, SELF LOCKING (23X)

901851011000

901851012000

10,38 €

Unit Price Incl. Tax

SPRING, TENSION

905062381100 905062381100

5,18 €

Unit Price Incl. Tax

SPRING, TENSION

905061680600 905061680600

2,98 €

Unit Price Incl. Tax

STOPPER, MAIN STAN

5CAF71140000 5CAF71140000

2,79 €

Unit Price Incl. Tax

FOOTREST REAR 1

1DKF74310300

Not available

FOOTREST REAR 2

1DKF74410300

Not available

BOLT, BUTTON HEAD

920120802000 920120802000

3,10 €

Unit Price Incl. Tax

NOT AVAILABLE

1DKF74530000

Not available

SCREW, TRUSS TAP.

977075001200 977075001200

1,14 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STAND / FOOTREST of your Yamaha SMAX of 2020. Let us know if you have any questions.
