FUEL TANK

SEAT FOR YAMAHA HW151 2012

FRONT WHEEL

Item numbers

DOUBLE SEAT ASSY

52SF47300000 52SF47300000

365,83 €

Unit Price Incl. Tax

SEAL

52SF475M0000 52SF475M0000

14,94 €

Unit Price Incl. Tax

HINGE, SEAT

52SF47260000 52SF47260000

5,47 €

Unit Price Incl. Tax

NUT, FLANGE(7NB)

957020650000

957010650000

2,23 €

Unit Price Incl. Tax

PIN, SEAT FITTING

52SF47270000 52SF47270000

2,79 €

Unit Price Incl. Tax

BOX 1

52SF473R0000 52SF473R0000

15,83 €

Unit Price Incl. Tax

BOLT

901090604300 901090604300

2,19 €

Unit Price Incl. Tax

SEAT HANDLE ASSY.

52SF477D00P0 52SF477D00P0

533,55 €

Unit Price Incl. Tax

ASSIST, GRIP

52SF474A00P0 52SF474A00P0

137,51 €

Unit Price Incl. Tax

ASSIST, GRIP 2

52SF474W00P0 52SF474W00P0

137,51 €

Unit Price Incl. Tax

NOT AVAILABLE

52SF481600P0

Not available

BRACKET, SEAT LEVE

52SF475H0000 52SF475H0000

56,96 €

Unit Price Incl. Tax

BLT, HEX, 1/4-20X5/8 10PK

958220801600

958110801600

2,12 €

Unit Price Incl. Tax

COLLAR 1

52SF471N0000 52SF471N0000

2,90 €

Unit Price Incl. Tax

PAD, SEAT

52SF47410000 52SF47410000

2,08 €

Unit Price Incl. Tax

BOLT, FLANGE

958220801200

958110801200

1,89 €

Unit Price Incl. Tax

PLATE, COVER

52SF471P0000 52SF471P0000

1,89 €

Unit Price Incl. Tax

DAMPER, SEAT

5NNF47370000 5NNF47370000

1,82 €

Unit Price Incl. Tax

NUT, SPRING(1YT) 5PK

901830580700

901830504200

1,14 €

Unit Price Incl. Tax

BOLT, FLANGE(8AB)

958220802000

958210802000

1,11 €

Unit Price Incl. Tax

COLLAR 1

52SF471N0000 52SF471N0000

2,90 €

Unit Price Incl. Tax

CAP

52SF482H0000 52SF482H0000

1,82 €

Unit Price Incl. Tax

SEAT LOCK ASSY

52SF47800000

52SF47800100

50,59 €

Unit Price Incl. Tax

BOLT, FLANGE (29L)

958020601000

958010601000

1,14 €

Unit Price Incl. Tax

CABLE, SEAT LOCK

52SF478E0000 52SF478E0000

22,20 €

Unit Price Incl. Tax

SCREW, PAN HEAD(3YL) 5PK

985020501400

985800501400

2,23 €

Unit Price Incl. Tax

PROTECTOR, 1

52SF476U0000 52SF476U0000

11,89 €

Unit Price Incl. Tax

LOCK ASSY 2

52SF17080000

52SF17080100

23,73 €

Unit Price Incl. Tax

O/M HW151'12

52SF8199F000 52SF8199F000

46,30 €

Unit Price Incl. Tax

O/M HW151'12

52SF8199G000 52SF8199G000

46,30 €

Unit Price Incl. Tax

O/M HW151'12

52SF8199H000 52SF8199H000

46,30 €

Unit Price Incl. Tax

O/M HW151'12

52SF8199S000 52SF8199S000

46,30 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
