CAMSHAFT / TIMING CHAIN

WATERPUMP / HOSES FOR YAMAHA MIDNIGHT STAR 1300 UBS 2016

RADIATOR / HOSES

Item numbers

WATER PUMP ASSY

3D8124200300 3D8124200300

582,65 €

Unit Price Incl. Tax

BRG, R-B 6001 28MM 28G KY

933060010600

933060010500

18,68 €

Unit Price Incl. Tax

OIL SEAL

931021237200 931021237200

7,42 €

Unit Price Incl. Tax

SEAL, MECHANICAL

5VK124380000 5VK124380000

38,92 €

Unit Price Incl. Tax

IMPELLER SHAFT ASSY

3D8124500100 3D8124500100

95,58 €

Unit Price Incl. Tax

O-RING

3D8124390000 3D8124390000

17,92 €

Unit Price Incl. Tax

COVER, HOUSING

3D8124220000 3D8124220000

138,99 €

Unit Price Incl. Tax

BOLT, SOCKET

913120602500

913160602500

2,08 €

Unit Price Incl. Tax

PIN, DOWEL

936031707000 936031707000

Not available

ROTOR ASSY 1

3D8133100000 3D8133100000

58,30 €

Unit Price Incl. Tax

PIN, DOWEL (603)

936031200700 936031200700

2,68 €

Unit Price Incl. Tax

HOUSING, ROTOR

3D8133360000 3D8133360000

125,16 €

Unit Price Incl. Tax

CIRCLIP(10Y)

990091240000 990091240000

2,23 €

Unit Price Incl. Tax

SPROCKET, DRIVEN

3D8133550000 3D8133550000

34,00 €

Unit Price Incl. Tax

BOLT, FLANGE

901050606600 901050606600

2,52 €

Unit Price Incl. Tax

STRAINER, OIL

3D8134110000 3D8134110000

17,92 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

901100804900 901100804900

7,81 €

Unit Price Incl. Tax

PIN, DOWEL(6G8)

995300801200 995300801200

1,93 €

Unit Price Incl. Tax

PIPE 9

3D81248E0100 3D81248E0100

71,11 €

Unit Price Incl. Tax

O-RING(1KT)

932102737000

932102777800

7,75 €

Unit Price Incl. Tax

BOLT, SOCKET

901100618200

913120601200

1,44 €

Unit Price Incl. Tax

BODY, DRAIN COCK

27D125620000 27D125620000

96,92 €

Unit Price Incl. Tax

O-RING (32N)

932101563900 932101563900

1,89 €

Unit Price Incl. Tax

O-RING (11M)

932100700300

Not available

BOLT, HEXAGON SOCKET HEAD

901100621900 901100621900

1,29 €

Unit Price Incl. Tax

PIPE, WATER

3D8125640000 3D8125640000

171,14 €

Unit Price Incl. Tax

O-RING

93210235A100 93210235A100

6,51 €

Unit Price Incl. Tax

BOLT, SOCKET

901100620800

913170603500

1,93 €

Unit Price Incl. Tax

BOLT, SOCKET

901100616100

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
