ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA XJR1300 2006

BATTERY (YT14B-BS)

5EA821001100

Not available

NOT AVAILABLE

5EA821160000

Not available

CLAMP(4FM)

904641519500 904641519500

3,10 €

Unit Price Incl. Tax

BAND 5PK

1UA825910000 1UA825910000

2,60 €

Unit Price Incl. Tax

STARTER RELAY ASSY (MS5E-491)

4KG819401100 4KG819401100

141,24 €

Unit Price Incl. Tax

BOLT, SMALL FLANGE

950270600800 950270600800

0,98 €

Unit Price Incl. Tax

NOT AVAILABLE

5WM825900000

Not available

FUSE (40A-BL)

5EA821510000 5EA821510000

21,21 €

Unit Price Incl. Tax

FUSE (12V 15A)

36Y821510000 36Y821510000

4,78 €

Unit Price Incl. Tax

FUSE (10A)

42X821510000 42X821510000

6,38 €

Unit Price Incl. Tax

SCREW, TRUSS TAP.

977076001600 977076001600

1,11 €

Unit Price Incl. Tax

PLUG(4BP)

903380822600 903380822600

2,19 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

BAND 5PK

1UA825910000 1UA825910000

2,60 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

RELAY ASSY (5EA-01) DISCONTINUED

5EA819501000 5EA819501000

Not available

RELAY ASSY (5EA-02)

5EA819502000 5EA819502000

103,05 €

Unit Price Incl. Tax

HOLDER, RELAY

5EA819520000 5EA819520000

7,20 €

Unit Price Incl. Tax

MAIN SW. IMMOBILIZER KIT

5WMW82500000 5WMW82500000

1 891,75 €

Unit Price Incl. Tax

IGNITOR UNIT ASSY

5WM823050000 5WM823050000

744,57 €

Unit Price Incl. Tax

NOT AVAILABLE

5WM8255P0000

Not available

SCREW

5SL821130000

5SL821130100

2,68 €

Unit Price Incl. Tax

BLANK KEY

5SL825110800 5SL825110800

93,90 €

Unit Price Incl. Tax

BOLT

90109080G500

901090817200

6,09 €

Unit Price Incl. Tax

NOT AVAILABLE

3YF825300100

Not available

NOT AVAILABLE

3LD825669100

Not available

SCREW, PAN HEAD(JJ6)

901570500800

985070501600

1,14 €

Unit Price Incl. Tax

CLAMP(4GY)

904641019000 904641019000

3,75 €

Unit Price Incl. Tax

HOUSING, CONNECTEUR 1

5VS8258J0000 5VS8258J0000

18,17 €

Unit Price Incl. Tax

HOUSING, CONNECTEUR 2

5VS8259J0000 5VS8259J0000

3,32 €

Unit Price Incl. Tax

NOT AVAILABLE

5WM816140000

Not available

THERMO SWITCH ASSY

5FU825605000 5FU825605000

26,45 €

Unit Price Incl. Tax

RELAY ASSY

5DM819500000

5DM819500100

58,81 €

Unit Price Incl. Tax

SCREW, BINDING

989070601200 989070601200

1,82 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha XJR1300 of 2006. Let us know if you have any questions.
