STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA XVZ13AH 1996

TRANSMISSION

NOT AVAILABLE

4NK161500100

Not available

PLATE, THRUST 1

26H161540000 26H161540000

11,89 €

Unit Price Incl. Tax

NOT AVAILABLE

1FK163710000

Not available

RING, CLUTCH BOSS

26H163850000 26H163850000

5,85 €

Unit Price Incl. Tax

PLATE, SEAT

26H163840000 26H163840000

14,05 €

Unit Price Incl. Tax

SPRING, CLUTCH BOSS

1FK163830000 1FK163830000

89,79 €

Unit Price Incl. Tax

PLATE, FRICTION

26H163210000

26H163210100

30,80 €

Unit Price Incl. Tax

PLATE, CLUTCH 1

26H163240000

Not available

PLATE, FRICTION 3

26H163070000

26H163070100

29,94 €

Unit Price Incl. Tax

PLATE, CLUTCH 1

26H163240000

Not available

PLATE, PRESSURE 1

1FK163510000 1FK163510000

137,43 €

Unit Price Incl. Tax

SPRING, CLUTCH 2

4NK163340000 4NK163340000

88,24 €

Unit Price Incl. Tax

HOUSING, SPRING

1FK163350000 1FK163350000

25,26 €

Unit Price Incl. Tax

PLATE, PRESSURE 2

1FK163520000 1FK163520000

17,04 €

Unit Price Incl. Tax

BOLT, HEXAGON

970170602500 970170602500

1,89 €

Unit Price Incl. Tax

BEARING(2JN)

933060031500 933060031500

43,19 €

Unit Price Incl. Tax

WASHER, LOCK (26H)

902152521800 902152521800

5,18 €

Unit Price Incl. Tax

NUT (26H)

901702032300 901702032300

13,62 €

Unit Price Incl. Tax

ROD, PUSH 1

4KG163560000 4KG163560000

35,77 €

Unit Price Incl. Tax

O-RING (26H)

932100663200 932100663200

2,90 €

Unit Price Incl. Tax

ROD, PUSH 2

4NK163570000 4NK163570000

18,51 €

Unit Price Incl. Tax

BALL (498) 5PK

935113202700 935113202700

3,32 €

Unit Price Incl. Tax

OIL SEAL(12E)

931090806100 931090806100

5,39 €

Unit Price Incl. Tax

GUIDE, PUSH ROD

26H163990000

26HY16390000

41,46 €

Unit Price Incl. Tax

O-RING (1L9) 5PK

932101832200 932101832200

3,79 €

Unit Price Incl. Tax

PIN, DOWEL

936030707300 936030707300

2,68 €

Unit Price Incl. Tax

PUSH LEVER COMP.

1FK163811100 1FK163811100

182,18 €

Unit Price Incl. Tax

BLEED SCREW KIT

1NLW00480000 1NLW00480000

19,27 €

Unit Price Incl. Tax

PUSH LEVER SEAL KIT

26HW00980000 26HW00980000

38,54 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD (4H7

901100603500 901100603500

2,79 €

Unit Price Incl. Tax

BOULON, TETE HEXAGONALE CREUSE

901100654300 901100654300

Not available

PIPE, CLUTCH 1

4NK1638A0000 4NK1638A0000

254,07 €

Unit Price Incl. Tax

WASHER, PLATE

902011011800

90201108J900

2,98 €

Unit Price Incl. Tax

BOLT, UNION(3GM)

904011015900 904011015900

7,33 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XVZ13AH of 1996. Let us know if you have any questions.
