LEG SHIELD FOR YAMAHA XC125 2010

COVER 1

Item numbers

LEG SHIELD 1

4C6XF83100P1 4C6XF83100P1

326,49 €

Unit Price Incl. Tax

DAMPER 1

5MLF834E0000 5MLF834E0000

1,93 €

Unit Price Incl. Tax

DAMPER

5MLF83720100 5MLF83720100

2,79 €

Unit Price Incl. Tax

DAMPER 1

5MLF15410000 5MLF15410000

1,93 €

Unit Price Incl. Tax

SCREW, WITH WASHER

901590682700 901590682700

1,89 €

Unit Price Incl. Tax

NUT, SPRING

901830580300

901830502400

2,48 €

Unit Price Incl. Tax

SCREW, TAPPING(4TV) 5PK

977075001600

901670507700

1,14 €

Unit Price Incl. Tax

GROMMET

904801339800

904801301400

2,79 €

Unit Price Incl. Tax

COLLAR(1LJ)

90387067N500 90387067N500

8,57 €

Unit Price Incl. Tax

NUT, FLANGE(4MV)

957070650000 957070650000

5,82 €

Unit Price Incl. Tax

LEG SHIELD ASSY

4C6F83000000 4C6F83000000

111,61 €

Unit Price Incl. Tax

SCREW, TAPPING(4TV) 5PK

977075001600

901670507700

1,14 €

Unit Price Incl. Tax

TAPPING SCREW

901690500100 901690500100

1,62 €

Unit Price Incl. Tax

CAP

5FMF83490000 5FMF83490000

4,99 €

Unit Price Incl. Tax

COLLAR

903870686800 903870686800

2,00 €

Unit Price Incl. Tax

SCREW, WITH WASHER (25G)

901590682200

901590606700

2,60 €

Unit Price Incl. Tax

MOLE 1

4P9F834500P1 4P9F834500P1

70,52 €

Unit Price Incl. Tax

EMBLEM

5MLF83152000 5MLF83152000

2,52 €

Unit Price Incl. Tax

NUT, SPRING(1YT) 5PK

901830580700

901830504200

1,14 €

Unit Price Incl. Tax

DUCT 1

5MLF838N0000

5MLF838N0100

37,23 €

Unit Price Incl. Tax

DUCT 2

5MLF838R0000 5MLF838R0000

10,43 €

Unit Price Incl. Tax

CLAMP, HOSE

5CAF18230000 5CAF18230000

6,30 €

Unit Price Incl. Tax

HOSE CLAMP ASSY

904505306100

904505300800

11,89 €

Unit Price Incl. Tax

BOLT(3KJ)

90109063F100 90109063F100

1,14 €

Unit Price Incl. Tax

COVER, LOWER

4C6F83850100 4C6F83850100

65,19 €

Unit Price Incl. Tax

DAMPER

4P9F83710000 4P9F83710000

14,72 €

Unit Price Incl. Tax

C0LLAR

90387062M900 90387062M900

4,56 €

Unit Price Incl. Tax

NUT

901790683300 901790683300

1,89 €

Unit Price Incl. Tax

SCREW, TRUSS TAP.

977075001200 977075001200

1,14 €

Unit Price Incl. Tax

NUT, SPRING(1YT) 5PK

901830580700

901830504200

1,14 €

Unit Price Incl. Tax

NOT AVAILABLE

5MLF415E0100

Not available

NOT AVAILABLE

5MLF15681000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
