CYLINDER HEAD FOR YAMAHA NXC125 2004

CRANKSHAFT / PISTON

Item numbers
CYLINDER HEAD Yamaha SCOOTER 125 2004 FLAME X NXC125
1
2
3
4
5
6
8
9
10
11
12
13
14
15
15
16
16
17
18
19
20
21
22
23
24
25
28
28
28
28
28
28
29
30
1
CYLINDER HEAD ASSY

5MLE11020000  

1P3E11020000
 5MLE11020000

Unit Price Incl. Tax

2
GUIDE, INTAKE VALVE

5ML111331000   5ML111331000

5ML111331000

Unit Price Incl. Tax

3
GUIDE, EXHAUST VALVE

5ML111341000   5ML111341000

5ML111341000

Unit Price Incl. Tax

4
BOLT, STUD

901160880600   901160880600

901160880600

Unit Price Incl. Tax

5
SCREW

901530680300  

901530604500
 901530680300

Unit Price Incl. Tax

6
GASKET 256113960000

904300601400   904300601400

904300601400
Not available
8
BREATHER ASSY

5MLE11600000   5MLE11600000

5MLE11600000

Unit Price Incl. Tax

9
COVER, CYLINDER HE

5MLE11850000   5MLE11850000

5MLE11850000

Unit Price Incl. Tax

10
PLATE, BREATHER

5MLE11650000   5MLE11650000

5MLE11650000

Unit Price Incl. Tax

11
BOLT, WITH WASHER(N30)

975270651200   975270651200

975270651200

Unit Price Incl. Tax

12
SEAL, LABYRINTH

4CWE11550000   4CWE11550000

4CWE11550000

Unit Price Incl. Tax

13
O-RING (5G2)

932107146200   932107146200

932107146200

Unit Price Incl. Tax

14
BOLT, FLANGE(6U1)

950270602000   950270602000

950270602000

Unit Price Incl. Tax

15
COVER, CYLINDER HE

5MLE11860000   5MLE11860000

5MLE11860000

Unit Price Incl. Tax

16
O-RING

932105480100  

932105400300
 932105480100

Unit Price Incl. Tax

17
WASHER, PLATE

902010860900  

90201080L700
 902010860900

Unit Price Incl. Tax

18
NUT, CROWN

901760881600   901760881600

901760881600

Unit Price Incl. Tax

19
PLUG, SPARK (CR7E)

947000084000  

947010035300
 947000084000

Unit Price Incl. Tax

20
GASKET, CYLINDER H

5MLE11810000   5MLE11810000

5MLE11810000

Unit Price Incl. Tax

21
PIN, DOWEL(3VD)

995301011400   995301011400

995301011400

Unit Price Incl. Tax

22
PIN, DOWEL(3VD)

995301011400   995301011400

995301011400

Unit Price Incl. Tax

23
BOLT, SOCKET HEAD

913170610000   913170610000

913170610000

Unit Price Incl. Tax

24
CYLINDER 1

5MLE13110000   5MLE13110000

5MLE13110000

Unit Price Incl. Tax

25
GASKET, CYLINDER

5MLE13510000  

5MLE13510100
 5MLE13510000

Unit Price Incl. Tax

28
BOLT, WASHER BASED(JA9)

950270601600  

901050669600
 950270601600

Unit Price Incl. Tax

29
BOLT, STUD 1

5MLE13910000   5MLE13910000

5MLE13910000

Unit Price Incl. Tax

30
BOLT, STUD 2

5MLE13920000   5MLE13920000

5MLE13920000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CYLINDER HEAD of your Yamaha NXC125 of 2004. Let us know if you have any questions.
