VALVE

CAMSHAFT / TIMING CHAIN FOR YAMAHA XTZ 125 E 2017

OIL PUMP

Item numbers

CAMSHAFT 1

1SBE21710000 1SBE21710000

184,11 €

Unit Price Incl. Tax

BEARING

93306003X600 93306003X600

9,35 €

Unit Price Incl. Tax

BEARING(4ES)

93306002Y100

933060021000

20,65 €

Unit Price Incl. Tax

COLLAR(50M)

90387167L500 90387167L500

21,54 €

Unit Price Incl. Tax

PLATE

5VLE111F0000 5VLE111F0000

2,83 €

Unit Price Incl. Tax

BOLT, SOCKET

913120601200

913170601200

1,44 €

Unit Price Incl. Tax

SPROCKET, CAM CHAIN

5VLE21760000 5VLE21760000

30,90 €

Unit Price Incl. Tax

WASHER (853)

902010887700 902010887700

3,10 €

Unit Price Incl. Tax

BOLT

901010882000

901010805500

2,19 €

Unit Price Incl. Tax

CHAIN

945802508800 945802508800

11,29 €

Unit Price Incl. Tax

GUIDE, STOPPER 1

5VLE22310000 5VLE22310000

21,03 €

Unit Price Incl. Tax

GUIDE, STOPPER 2

5VLE22410000 5VLE22410000

39,80 €

Unit Price Incl. Tax

COLLAR

5VLE55980000 5VLE55980000

2,08 €

Unit Price Incl. Tax

BOLT, FLANGE

958020602000

958010602000

1,82 €

Unit Price Incl. Tax

NOT AVAILABLE

5VLE22100100

Not available

GASKET, TENSIONER CASE

5VLE22131000 5VLE22131000

1,22 €

Unit Price Incl. Tax

BOLT, FLANGE

950220601600 950220601600

1,14 €

Unit Price Incl. Tax

GASKET 256113960000

904300681700

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
