ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA DTE125 1996

FLASHER RELAY ASSY

34L833502000 34L833502000

122,61 €

Unit Price Incl. Tax

HORN

3BN833710000

2KG833710000

41,77 €

Unit Price Incl. Tax

BOLT, FLANGE

958070601200

958170601200

0,80 €

Unit Price Incl. Tax

C.D.I. UNIT ASSY

3MB855400000

Not available

BAND

3MB855460000 3MB855460000

15,36 €

Unit Price Incl. Tax

NOT AVAILABLE

3BN819600100

Not available

SCREW, PAN

985070601200

985170601200

1,14 €

Unit Price Incl. Tax

WASHER(6TA)

929070660000 929070660000

1,14 €

Unit Price Incl. Tax

SERVO MOTOR ASSY

3MB858200000

Not available

GROMMET 839774310000

904801402300 904801402300

4,01 €

Unit Price Incl. Tax

COLLAR (1T2)

903870629900

903870759800

4,56 €

Unit Price Incl. Tax

WASHER, PLATE

902010606700

902010676500

2,19 €

Unit Price Incl. Tax

SCREW, PAN HEAD (76T)

985070602500

985170602500

1,11 €

Unit Price Incl. Tax

NOT AVAILABLE

34X858250100

Not available

SWITCH, SIDE STAND

3LD825665000

3LD825665100

119,33 €

Unit Price Incl. Tax

VIS, TETE TRONCONIQUE

985070501500 985070501500

Not available

THERMO UNIT

11H835910000 11H835910000

60,41 €

Unit Price Incl. Tax

RELAY ASSY

1RL819509200

12R819500100

117,45 €

Unit Price Incl. Tax

RELAY ASSY (29U-93)

29U819509300 29U819509300

109,31 €

Unit Price Incl. Tax

STARTER RELAY ASSY (MS5D-611)

3AY819400000

4KD819400000

136,42 €

Unit Price Incl. Tax

NUT, FLANGE(4MV)

957070650000 957070650000

6,21 €

Unit Price Incl. Tax

BAND

12R825910000 12R825910000

2,72 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha DTE125 of 1996. Let us know if you have any questions.
