Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

REAR BRAKE MASTER CYLINDER

IGNITION FOR YAMAHA VMX12 2002

IGNITION PICKUP

IGNITION Yamaha MOTO 1200 2002 VMAX VMX12
1
STATOR ASSY

3UF814101000   3UF814101000

3UF814101000

Unit Price Incl. Tax

2
ROTOR ASSY

3UF814501000   3UF814501000

3UF814501000

Unit Price Incl. Tax

3
PICK-UP ASSY

3UF816700000   3UF816700000

3UF816700000

Unit Price Incl. Tax

4
SCREW, PAN

985070604000   985070604000

985070604000

Unit Price Incl. Tax

5
WASHER(6TA) 10PK

929070660000   929070660000

929070660000

Unit Price Incl. Tax

6
SCREW, PAN HEAD(3TJ)

985070601600   985070601600

985070601600

Unit Price Incl. Tax

7
WASHER, PLATE

902010667400  

902010664300
 902010667400

Unit Price Incl. Tax

8
PLATE, STAT0R

59J151130000   59J151130000

59J151130000

Unit Price Incl. Tax

9
PLATE, C0VER

59J151910000   59J151910000

59J151910000

Unit Price Incl. Tax

10
SEPARATOR, OIL

1FK153580000   1FK153580000

1FK153580000

Unit Price Incl. Tax

11
SEAL, CRANKCASE

1FK153790000   1FK153790000

1FK153790000

Unit Price Incl. Tax

12
SEAL, PROTECTOR

1FK154940000   1FK154940000

1FK154940000

Unit Price Incl. Tax

13
SCREW, PAN

985070601200  

985070601200
Not available
14
WASHER(6TA) 10PK

929070660000   929070660000

929070660000

Unit Price Incl. Tax

15
SHAFT 1

59J114550000   59J114550000

59J114550000

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the IGNITION of your Yamaha VMX12 of 2002. Let us know if you have any questions.
