Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA XVS1100 2003

ELECTRICAL 2

Item numbers
ELECTRICAL 1 Yamaha MOTO 1100 2003 DRAGSTAR XVS1100 XVS11R V-STAR 1100 CUSTOM
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
1
NEUTRAL SWITCH ASSY

4KM825400000  

4GY825401000
 4KM825400000

Unit Price Incl. Tax

2
GASKET (1KH, 1.0T)

904301014800   904301014800

904301014800

Unit Price Incl. Tax

3
IGNITOR UNIT ASSY

5EL823050000   5EL823050000

5EL823050000

Unit Price Incl. Tax

4
SCREW, TRUSS TAP.

977076001600   977076001600

977076001600

Unit Price Incl. Tax

5
PLUG(4BP)

903380822600   903380822600

903380822600

Unit Price Incl. Tax

6
IGNITION COIL ASSY

5EL823100000   5EL823100000

5EL823100000

Unit Price Incl. Tax

7
BOLT (2E9)

970070502000  

970270502000
 970070502000

Unit Price Incl. Tax

8
WASHER(1RW)

929070560000   929070560000

929070560000

Unit Price Incl. Tax

9
IGNITION COIL ASSY

5EL823200000   5EL823200000

5EL823200000

Unit Price Incl. Tax

10
BOLT (2E9)

970070502000  

970270502000
 970070502000

Unit Price Incl. Tax

11
WASHER(1RW)

929070560000   929070560000

929070560000

Unit Price Incl. Tax

12
PLUG CAP ASSY

5EL823700000   5EL823700000

5EL823700000

Unit Price Incl. Tax

13
SENSOR, SPEED

5EL837550000  

5EL837550100
 5EL837550000

Unit Price Incl. Tax

14
BOLT, SOCKET

913170601200   913170601200

913170601200

Unit Price Incl. Tax

15
NOT AVAILABLE

5EL825090000  

5EL825090000
Not available
16
OIL LEVEL GAUGE ASSY

5EL857200100  

5EL857200200
 5EL857200100

Unit Price Incl. Tax

17
BOLT, SOCKET

913170601600   913170601600

913170601600
Not available
18
FLASHER RELAY ASSY

5EL833500000  

5EL833500100
 5EL833500000

Unit Price Incl. Tax

19
NOT AVAILABLE

55V833710000  

55V833710000
Not available
20
BOLT, WASHER BASED

90105082A500   90105082A500

90105082A500

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
