CYLINDER HEAD

CRANKSHAFT / PISTON FOR YAMAHA T105E 2002

VALVE

Item numbers

CRANKSHAFT ASSY

5AVE14002000 5AVE14002000

421,80 €

Unit Price Incl. Tax

NOT AVAILABLE

5AVE14120000

Not available

PIN, CRANK 1 (VEGA-R)

5AVE16810000

5LME16810000

63,42 €

Unit Price Incl. Tax

BEARING, CYLINDRICAL(4CW)

93310326M900 93310326M900

48,70 €

Unit Price Incl. Tax

ROD, CONNECTING

5AVE16510000 5AVE16510000

32,40 €

Unit Price Incl. Tax

CRANK 2

5AVE14220000 5AVE14220000

75,09 €

Unit Price Incl. Tax

GEAR, DRIVE

5AVE15360000 5AVE15360000

26,31 €

Unit Price Incl. Tax

BEARING

933062059500 933062059500

28,22 €

Unit Price Incl. Tax

KEY WOODRUFF 146115450000

902800301700 902800301700

3,32 €

Unit Price Incl. Tax

PISTON (0.25MM O/S

4STE16350100 4STE16350100

30,15 €

Unit Price Incl. Tax

PISTON (0.50MM O/S

4STE16360100 4STE16360100

30,15 €

Unit Price Incl. Tax

PISTON (0.75MM O/S

4STE16370100 4STE16370100

30,15 €

Unit Price Incl. Tax

PISTON (1.00MM O/S) T10

4STE16380100 4STE16380100

30,15 €

Unit Price Incl. Tax

PISTON (STD)

5AVE16310100

4STE16310100

30,52 €

Unit Price Incl. Tax

PIN, PISTON

5AVE16330000

22K116330100

4,15 €

Unit Price Incl. Tax

CIRCLIP (22F)

934501408800 934501408800

1,14 €

Unit Price Incl. Tax

PISTON RING SET (2ND O/S)

50M116102000 50M116102000

81,98 €

Unit Price Incl. Tax

PISTON RING SET (4TH O/S)

50M116104000 50M116104000

81,98 €

Unit Price Incl. Tax

COUVERCLE 1

50M146040000 50M146040000

Not available

PISTON RING SET (0.75MM O/S)

50M146060000 50M146060000

Not available

PISTON RING SET (STD)

5AVE16100000

50M116100000

66,91 €

Unit Price Incl. Tax

NOT AVAILABLE

5AVE15000000

Not available

BRG, R-B (7H4)

933062022900

933062021100

26,74 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Yamaha T105E of 2002. Let us know if you have any questions.
