STAND / FOOTREST

LEG SHIELD FOR YAMAHA T105SE 2004

IGNITION

(1) 5AV-F8311-20-P3

PROTEGE-JAMBES 1

(2) 5AV-F8368-70

EMBLEME

(3) 90387-060G7

COLLAR(47X)

(4) 985170602000

SCREW, PAN

(5) 902010602000

WASHER, PLATE

(6) 904801301400

GROMMET

(7) 5AV-F8312-20-P3

PROTEGE-JAMBES 2

(8) 90387-060G7

COLLAR(47X)

(9) 985170602000

SCREW, PAN

(10) 902010602000

WASHER, PLATE

(11) 904801301400

GROMMET

(12) 5AV-F8321-00

STAY 1

(13) 958170601400

BOLT, FLANGE

(14) 90560-06201

SPACER (4F2)

(15) 90480-13018

GROMMET (462)

(16) 970170602000

BOLT, HEXAGON

(17) 5AV-F8322-00

STAY 2

(18) 5AV-F8385-00-P3

COUVERCLE

(19) 5AV-F8391-70

GRAPHIQUE, DE CARENAGE 1

(20) 5AV-F8435-00

DAMPER 4

(21) 5AV-F834W-00

PROTECTEUR 2

(22) 5AV-F8395-00-P3

COUVERCLE INFERIEUR

(23) 5AV-F8392-70

GRAPHIQUE, DE CARENAGE 2

(24) 5AV-F8435-00

DAMPER 4

(25) 5AV-F3398-00

MOLD, FRONT

(26) 90159-06817

SCREW, WITH WASHER

(27) 5AV-F834V-00

PROTECTOR 1

(28) 5AV-F836T-00

DAMPER, LOCATING 1

	Part number	Description	Qty
# 1	5AV-F8311-20-P3 5AVF831120P3 5AVF831120P3	PROTEGE-JAMBES 1	Not available	0,00 €
# 2	5AV-F8368-70 5AVF836870 5AVF836870	EMBLEME	Not available	0,00 €
# 3	90387-060G7 90387060G7 90387060G7	COLLAR(47X)	1,61 €
# 4	90159-06085 985170602000 9015906085	SCREW, PAN	1,92 €
# 5	90201-06557 902010602000 9020106557	WASHER, PLATE	3,37 €
# 6	90480-13398 904801301400 9048013398	GROMMET	2,32 €
# 7	5AV-F8312-20-P3 5AVF831220P3 5AVF831220P3	PROTEGE-JAMBES 2	Not available	0,00 €
# 8	90387-060G7 90387060G7 90387060G7	COLLAR(47X)	1,61 €
# 9	90159-06085 985170602000 9015906085	SCREW, PAN	1,92 €
# 10	90201-06557 902010602000 9020106557	WASHER, PLATE	3,37 €
# 11	90480-13398 904801301400 9048013398	GROMMET	2,32 €
# 12	5AV-F8321-00 5AVF832100 5AVF832100	STAY 1	1,23 €
# 13	95807-06014 958170601400 9580706014	BOLT, FLANGE	0,96 €
# 14	90560-06201 9056006201 9056006201	SPACER (4F2)	9,96 €
# 15	90480-13018 9048013018 9048013018	GROMMET (462)	1,61 €
# 16	97007-06020 970170602000 9700706020	BOLT, HEXAGON	0,87 €
# 17	5AV-F8322-00 5AVF832200 5AVF832200	STAY 2	1,23 €
# 18	5AV-F8385-00-P3 5AVF838500P3 5AVF838500P3	COUVERCLE	Not available	0,00 €
# 19	5AV-F8391-70 5AVF839170 5AVF839170	GRAPHIQUE, DE CARENAGE 1	Not available	0,00 €
# 20	5AV-F8435-00 5AVF843500 5AVF843500	DAMPER 4	0,50 €
# 21	5AV-F834W-00 5AVF834W00 5AVF834W00	PROTECTEUR 2	Not available	0,00 €
# 22	5AV-F8395-00-P3 5AVF839500P3 5AVF839500P3	COUVERCLE INFERIEUR	Not available	0,00 €
# 23	5AV-F8392-70 5AVF839270 5AVF839270	GRAPHIQUE, DE CARENAGE 2	Not available	0,00 €
# 24	5AV-F8435-00 5AVF843500 5AVF843500	DAMPER 4	0,50 €
# 25	5AV-F3398-00 5AVF339800 5AVF339800	MOLD, FRONT	Not available	0,00 €
# 26	90159-06817 9015906817 9015906817	SCREW, WITH WASHER	0,36 €
# 27	5AV-F834V-00 5AVF834V00 5AVF834V00	PROTECTOR 1	Not available	0,00 €
# 28	5AV-F836T-00 5AVF836T00 5AVF836T00	DAMPER, LOCATING 1	0,96 €

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the LEG SHIELD of your Yamaha T105SE of 2004. Let us know if you have any questions.
