SIDE COVER

SWINGARM FOR YAMAHA R1 2024

REAR SUSPENSION

Item numbers

REAR ARM COMP.

B3L221100000 B3L221100000

3 136,94 €

Unit Price Incl. Tax

BOLT

901010801300 901010801300

1,82 €

Unit Price Incl. Tax

NUT

953020860000 953020860000

Not available

WASHER, PLATE

902010805700 902010805700

2,83 €

Unit Price Incl. Tax

BUSH

2CR221840000 2CR221840000

90,92 €

Unit Price Incl. Tax

BEARING

933175289700 933175289700

55,88 €

Unit Price Incl. Tax

BEARING, CYLINDRICAL(6U4)

93317428U800 93317428U800

61,50 €

Unit Price Incl. Tax

COVER, THRUST 1

5VY221280000 5VY221280000

20,48 €

Unit Price Incl. Tax

COVER, THRUST 1

4C8221280000 4C8221280000

20,48 €

Unit Price Incl. Tax

WASHER, PLATE

902012201900 902012201900

12,46 €

Unit Price Incl. Tax

ARM, RELAY

B3L2217A0000 B3L2217A0000

196,49 €

Unit Price Incl. Tax

COLLAR

903871012A00 903871012A00

13,94 €

Unit Price Incl. Tax

BEARING

933153175900 933153175900

32,52 €

Unit Price Incl. Tax

BEARING

933153175800 933153175800

22,93 €

Unit Price Incl. Tax

OIL SEAL

931091707100 931091707100

4,82 €

Unit Price Incl. Tax

COLLAR(4BH)

90387126Y100 90387126Y100

22,41 €

Unit Price Incl. Tax

ARM 1

2CR2217M0000 2CR2217M0000

55,74 €

Unit Price Incl. Tax

BOLT

901091201000 901091201000

20,74 €

Unit Price Incl. Tax

WASHER(6TA)

929021260000

929071260000

1,14 €

Unit Price Incl. Tax

NUT, SELF-LOCKING

901851201100 901851201100

8,45 €

Unit Price Incl. Tax

SEAL, GUARD

2CR221511000 2CR221511000

65,19 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920120601600 920120601600

1,29 €

Unit Price Incl. Tax

RIVET

902690700700 902690700700

2,08 €

Unit Price Incl. Tax

COLLAR

903870624200 903870624200

4,78 €

Unit Price Incl. Tax

CASE CHAIN

2CR223110000 2CR223110000

37,16 €

Unit Price Incl. Tax

RIVET

902690700700 902690700700

2,08 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD(3HE)

901100620000 901100620000

3,75 €

Unit Price Incl. Tax

REAR FENDER COMP.

2CR216500100 2CR216500100

178,89 €

Unit Price Incl. Tax

SPACER (25G)

905600624400 905600624400

3,32 €

Unit Price Incl. Tax

BOLT, BUTTON

920140601600 920140601600

2,12 €

Unit Price Incl. Tax

BOLT, WASHER BASED

901051001700 901051001700

19,48 €

Unit Price Incl. Tax

NUT, U FLANGE

956021020000 956021020000

4,56 €

Unit Price Incl. Tax

NOT AVAILABLE

5UY212690000

Not available

SHAFT, PIVOT

14B221410000 14B221410000

143,43 €

Unit Price Incl. Tax

NUT, SELF-LOCKING

901852000800 901852000800

18,51 €

Unit Price Incl. Tax

WASHER, PLATE

902012002600 902012002600

12,84 €

Unit Price Incl. Tax

WASHER, PLATE

902013001600 902013001600

17,47 €

Unit Price Incl. Tax

NUT

4C8222520000 4C8222520000

21,54 €

Unit Price Incl. Tax

COLLAR

903871012B00 903871012B00

17,37 €

Unit Price Incl. Tax

BOLT

901091001700 901091001700

16,75 €

Unit Price Incl. Tax

NUT, U FLANGE

956021020000 956021020000

4,56 €

Unit Price Incl. Tax

LABEL, TIRE

BM6216680100 BM6216680100

5,60 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SWINGARM of your Yamaha R1 of 2024. Let us know if you have any questions.
