ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA YZF-R1 2011

Item numbers

HORN

14B833710000 14B833710000

111,54 €

Unit Price Incl. Tax

BOLT, FLANGE(2HR)

958020601200

958010601200

1,03 €

Unit Price Incl. Tax

SWITCH, SIDE STAND

13S825665000 13S825665000

100,61 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920120502500 920120502500

1,29 €

Unit Price Incl. Tax

NUT, U FLANGE

956020520000

956010520000

2,90 €

Unit Price Incl. Tax

BRACKET, SENSOR 1

14B279610000 14B279610000

10,38 €

Unit Price Incl. Tax

BOLT, BUTTON HEAD

920120501600 920120501600

1,14 €

Unit Price Incl. Tax

HOLDER

14B279110000 14B279110000

12,72 €

Unit Price Incl. Tax

BRACKET 5

14B2836H0000 14B2836H0000

25,39 €

Unit Price Incl. Tax

BOLT, HEX. SOCKET BUTTON

901110611900 901110611900

4,56 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

901100624500 901100624500

2,12 €

Unit Price Incl. Tax

PLUG(1NL)

903380601800

903380618100

7,07 €

Unit Price Incl. Tax

BRACKET 6

14B2836J0000 14B2836J0000

17,84 €

Unit Price Incl. Tax

NUT, SPRING(4ES)

901830606900 901830606900

2,52 €

Unit Price Incl. Tax

BOLT, HEXAGON SOCKET HEAD

901100624500 901100624500

2,12 €

Unit Price Incl. Tax

WIRE, MINUS LEAD

14B821160000 14B821160000

46,38 €

Unit Price Incl. Tax

BOLT, SOCKET

913120601200

913170601200

1,44 €

Unit Price Incl. Tax

BATTERY (YTZ10S)

5VY821000000 5VY821000000

214,12 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

14B825903000 14B825903000

2 238,42 €

Unit Price Incl. Tax

FUSE

5JJ821512000 5JJ821512000

4,70 €

Unit Price Incl. Tax

FUSE (15A)

5JJ821511000

67F821515000

2,42 €

Unit Price Incl. Tax

FUSE (7.5A-BL)

5JJ821510000 5JJ821510000

4,70 €

Unit Price Incl. Tax

FUSE (50A)

5JW821511000 5JW821511000

28,83 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

1D7819600000

1D7819600100

438,85 €

Unit Price Incl. Tax

BOLT, FLANGE

901050614800 901050614800

1,11 €

Unit Price Incl. Tax

FLASHER RELAY ASSY

4GY833500000

4GY833500100

115,56 €

Unit Price Incl. Tax

RELAY ASSY (5VK-40)

5VK819504000

Not available

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-054)

2C0819400000 2C0819400000

121,52 €

Unit Price Incl. Tax

FUSE (12V 15A)

36Y821510000 36Y821510000

4,78 €

Unit Price Incl. Tax

BOLT, FLANGE

950220600800 950220600800

1,03 €

Unit Price Incl. Tax

COVER, LEAD WIRE

5SL821191000 5SL821191000

6,16 €

Unit Price Incl. Tax

SENSOR, LEAN ANGLE

5VU825760100

5VU825760200

170,92 €

Unit Price Incl. Tax

BOLT

913120402500 913120402500

1,11 €

Unit Price Incl. Tax

WASHER, PLATE (8M6)

90201047A200 90201047A200

4,70 €

Unit Price Incl. Tax

NUT, SPRING(47R)

901830403900 901830403900

10,09 €

Unit Price Incl. Tax

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP (6E5)

9046513M1100 9046513M1100

2,41 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

CLAMP

904641200900 904641200900

3,58 €

Unit Price Incl. Tax

CLAMP

904641600100 904641600100

2,68 €

Unit Price Incl. Tax

CLAMP

904643600400 904643600400

10,38 €

Unit Price Incl. Tax

HOSE (L30)

90445107A500 90445107A500

1,11 €

Unit Price Incl. Tax

CLAMP

904642125600 904642125600

4,82 €

Unit Price Incl. Tax

BAND 5PK

904641606100

12R825910000

2,60 €

Unit Price Incl. Tax

CLAMP

904645900100 904645900100

18,39 €

Unit Price Incl. Tax

CLAMP(2TV) 5PK

904641208900

904641011200

5,52 €

Unit Price Incl. Tax

STOP SWITCH ASSY

14B825300000

14B825300100

52,51 €

Unit Price Incl. Tax

STAY, STOP SWITCH

14B2144G0000 14B2144G0000

9,74 €

Unit Price Incl. Tax

GROMMET(4SV)

904801260700 904801260700

7,20 €

Unit Price Incl. Tax

COLLAR

9038706M1600 9038706M1600

1,40 €

Unit Price Incl. Tax

SCREW, PAN HEAD(3TJ)

901590615000

901590608200

1,14 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha YZF-R1 of 2011. Let us know if you have any questions.
