ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA FZ1-SW 2007

SWITCH, SIDE STAND

5VS825666100

Not available

BOLT, BUTTON HEAD

920170503000 920170503000

1,40 €

Unit Price Incl. Tax

NUT, U FLANGE

956070520000 956070520000

2,90 €

Unit Price Incl. Tax

STOP SWITCH ASSY

2D1825300000 2D1825300000

83,03 €

Unit Price Incl. Tax

MAIN SW. IMMOBILIZER KIT

2D1W82500100

2D1W82502000

1 827,36 €

Unit Price Incl. Tax

NOT AVAILABLE

2D1W82501100

Not available

ENGINE CONTROL UNIT ASSY

2D18591A0100

2D18591A2000

1 022,31 €

Unit Price Incl. Tax

ENGINE CONTROL UNIT ASSY

2D18591A1100

2D18591A3000

1 022,31 €

Unit Price Incl. Tax

IMMOBILIZER. UNIT COMP.

2D18255P0000 2D18255P0000

640,01 €

Unit Price Incl. Tax

SCREW

5SL821130000

5SL821130100

2,68 €

Unit Price Incl. Tax

BLANK KEY

5SL825110800 5SL825110800

93,90 €

Unit Price Incl. Tax

BATTERY (YTZ14S)

2D1821000000 2D1821000000

254,66 €

Unit Price Incl. Tax

COVER, BATTERY

2D1821290000

Not available

BAND, BATTERY

2D1821310000 2D1821310000

10,91 €

Unit Price Incl. Tax

HOOK

5YU2162A0000 5YU2162A0000

8,14 €

Unit Price Incl. Tax

STARTER RELAY ASSY (RC19-054)

2C0819400000 2C0819400000

121,52 €

Unit Price Incl. Tax

FUSE (12V 15A)

36Y821510000 36Y821510000

4,78 €

Unit Price Incl. Tax

COVER, LEAD WIRE

5SL821191000 5SL821191000

6,16 €

Unit Price Incl. Tax

DAMPER

2D1821760000 2D1821760000

2,00 €

Unit Price Incl. Tax

BOLT, SMALL FLANGE

950270600800 950270600800

0,98 €

Unit Price Incl. Tax

WIRE HARNESS ASSY

3C3825900000 3C3825900000

1 422,72 €

Unit Price Incl. Tax

FUSE (50A)

5JW821511000 5JW821511000

28,83 €

Unit Price Incl. Tax

FUSE (25A-BL)

5JJ821517000 5JJ821517000

4,70 €

Unit Price Incl. Tax

FUSE (15A)

5JJ821511000

67F821515000

2,42 €

Unit Price Incl. Tax

FUSE (10A)

5JJ821513000

67F821514000

11,05 €

Unit Price Incl. Tax

RECTIFIER & REGULATOR ASSY

1D7819600000

1D7819600100

438,85 €

Unit Price Incl. Tax

BOLT, FLANGE

958220602500

958170602500

1,11 €

Unit Price Incl. Tax

RELAY ASSY (5VK-40)

5VK819504000

Not available

RELAY ASSY (5JJ-20)

5JJ819502000 5JJ819502000

104,89 €

Unit Price Incl. Tax

HOLDER, RELAY

5JJ819520000 5JJ819520000

7,93 €

Unit Price Incl. Tax

SENSOR, LEAN ANGLE

5PS825760100 5PS825760100

123,62 €

Unit Price Incl. Tax

BOLT, SOCKET

913170402500 913170402500

0,73 €

Unit Price Incl. Tax

WASHER, PLATE (8M6)

90201047A200 90201047A200

4,70 €

Unit Price Incl. Tax

NUT, SPRING(47R)

901830403900 901830403900

10,09 €

Unit Price Incl. Tax

BOLT

90109080G500

901090817200

6,09 €

Unit Price Incl. Tax

CLAMP(2TV) 5PK

904641203600

904641011200

5,52 €

Unit Price Incl. Tax

BAND 5PK

1UA825910000 1UA825910000

2,60 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307300

904641519500

3,10 €

Unit Price Incl. Tax

PROTECTER, WIRE HARNESS

2D1825890000

2D1825890100

15,40 €

Unit Price Incl. Tax

CLAMP

904641201200 904641201200

3,87 €

Unit Price Incl. Tax

WIRE, MINUS LEAD

2D1821160000 2D1821160000

32,07 €

Unit Price Incl. Tax

HORN

2D1833710000 2D1833710000

78,87 €

Unit Price Incl. Tax

BAND

3MA825910000 3MA825910000

4,27 €

Unit Price Incl. Tax

FLASHER RELAY ASSY

4GY833500000

4GY833500100

115,56 €

Unit Price Incl. Tax

RELAY ASSY (5EA-02)

5EA819502000 5EA819502000

103,05 €

Unit Price Incl. Tax

HOLDER, RELAY

5EA819520000 5EA819520000

7,20 €

Unit Price Incl. Tax

RELAY ASSY

5DM819500000

5DM819500100

58,81 €

Unit Price Incl. Tax

CLAMP(4FM)

904641307700

904641307300

3,10 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
