STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA XV1000 1986

TRANSMISSION

NOT AVAILABLE

4X7161110000

Not available

KEY, STRAIGHT (4X7)

902820704200 902820704200

6,42 €

Unit Price Incl. Tax

WASHER, CLAW (4X7)

902142002200 902142002200

19,18 €

Unit Price Incl. Tax

WASHER, LOCK

902152018200

902152000600

3,58 €

Unit Price Incl. Tax

NUT (4X7)

901702027400 901702027400

13,14 €

Unit Price Incl. Tax

HOUSING, PUSH SCREW

2H7163960000 2H7163960000

36,52 €

Unit Price Incl. Tax

PIN, DOWEL (296)

936060708200 936060708200

2,79 €

Unit Price Incl. Tax

RETAINER, BALL

2H7163950100 2H7163950100

13,80 €

Unit Price Incl. Tax

SCREW, PUSH

2H7163410000 2H7163410000

69,89 €

Unit Price Incl. Tax

SCREW, CLUTCH ADJUSTING

2H7163430000 2H7163430000

12,80 €

Unit Price Incl. Tax

O-RING (2H7) 5PK

932104836400 932104836400

2,90 €

Unit Price Incl. Tax

PUSH LEVER ASSY

4X7163400000 4X7163400000

17,84 €

Unit Price Incl. Tax

YBS66-8 WASHER, PLAIN

929010820000

929900820000

1,89 €

Unit Price Incl. Tax

NUT(661)

953010870000

Not available

SPRING TENSION 360163450000

905061006900 905061006900

3,10 €

Unit Price Incl. Tax

OIL SEAL (14X25X5-2H7)

931041405900 931041405900

7,45 €

Unit Price Incl. Tax

NOT AVAILABLE

4X7163570000

Not available

NOT AVAILABLE

4X7163560000

Not available

BEARING, THRUST (713)

933402150500 933402150500

25,10 €

Unit Price Incl. Tax

WASHER, PLATE (5G3)

90201151A700

90201154E900

3,58 €

Unit Price Incl. Tax

NOT AVAILABLE

4X7161500200

Not available

PLATE, THRUST 1

3Y1161540000 3Y1161540000

12,10 €

Unit Price Incl. Tax

NOT AVAILABLE

4X7163710000

Not available

PLATE, SEAT

4X7163840000 4X7163840000

14,60 €

Unit Price Incl. Tax

SPRING, CLUTCH BOSS

4X7163830000

4X7163830100

50,16 €

Unit Price Incl. Tax

PLATE, CLUTCH 1

4X7163240000

Not available

RING, CLUTCH BOSS

4X7163850000 4X7163850000

6,77 €

Unit Price Incl. Tax

PLATE, FRICTION

22U163210000 22U163210000

17,43 €

Unit Price Incl. Tax

PLATE, CLUTCH 2

4X7163250000

Not available

NOT AVAILABLE

4X7163510000

Not available

SPRING (583 CLUTCH)

905012339100 905012339100

7,24 €

Unit Price Incl. Tax

SCREW, WITH WASHER(33M)

901590609200 901590609200

3,10 €

Unit Price Incl. Tax

WASHER, LOCK (34L) 5PK

902152023100 902152023100

4,44 €

Unit Price Incl. Tax

NUT (34L)

901702025700

901702032700

10,09 €

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XV1000 of 1986. Let us know if you have any questions.
