CRANKSHAFT / PISTON

OIL PUMP FOR YAMAHA AG100F 1999

INTAKE

Item numbers
OIL PUMP Yamaha MOTO 100 1999 AG AG100F
1
2
3
4
5
6
7
8
9
10
10
10
11
12
13
15
16
17
18
19
20
21
22
23
24
1
OIL PUMP ASSY

3V6131010000   3V6131010000

3V6131010000

Unit Price Incl. Tax

2
BALL

935053200200   935053200200

935053200200

Unit Price Incl. Tax

3
SPRING, CHECK BALL (451)

905010221700   905010221700

905010221700

Unit Price Incl. Tax

4
HOSE (L700)

904450527800  

904450524200
 904450527800

Unit Price Incl. Tax

5
CLIP (214-13164-00) 5PK

904680203300   904680203300

904680203300
Not available
6
NOZZLE

402135520000   402135520000

402135520000

Unit Price Incl. Tax

7
GASKET 137131870000

904300400400   904300400400

904300400400

Unit Price Incl. Tax

8
SCREW, BINDING

989070400800   989070400800

989070400800

Unit Price Incl. Tax

9
PLATE, ADJUSTING

137131380100   137131380100

137131380100

Unit Price Incl. Tax

10
SHIM, PLUNGER

137131370003   137131370003

137131370003

Unit Price Incl. Tax

10
SHIM, PLUNGER

137131370005   137131370005

137131370005

Unit Price Incl. Tax

10
SHIM, PLUNGER

137131370010   137131370010

137131370010

Unit Price Incl. Tax

11
WASHER(3SX)

929070510000   929070510000

929070510000

Unit Price Incl. Tax

12
NUT, HEXAGON

953070560000  

953170560000
 953070560000

Unit Price Incl. Tax

13
COVER, ADJUST PULLEY

367131460100   367131460100

367131460100

Unit Price Incl. Tax

15
WASHER, PLATE (1E7)

902010862400   902010862400

902010862400

Unit Price Incl. Tax

16
GASKET, PUMP CASE

126131160100   126131160100

126131160100

Unit Price Incl. Tax

17
SCREW, PAN HEAD 10PK

985070501400   985070501400

985070501400

Unit Price Incl. Tax

18
OIL SEAL (10X22X7-137)

931011000200   931011000200

931011000200

Unit Price Incl. Tax

19
METAL, WORM SHAFT OUTER

137131760000   137131760000

137131760000

Unit Price Incl. Tax

20
GEAR, DRIVE

382131786000   382131786000

382131786000

Unit Price Incl. Tax

21
PIN, DOWEL (137) 5PK

936032202800   936032202800

936032202800

Unit Price Incl. Tax

22
CIRCLIP(2R6)

990010860000   990010860000

990010860000

Unit Price Incl. Tax

23
HOLDER, OIL PIPE

525131740000  

525131740100
 525131740000

Unit Price Incl. Tax

24
CLIP (214-13164-00) 5PK

904680203300   904680203300

904680203300
Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the OIL PUMP of your Yamaha AG100F of 1999. Let us know if you have any questions.
